All LEMOEN batteries use LifePO4 cells, our cell manufacturer is the leader in cell manufacturing for EV and Energy Storage batteries in the world.
Excellent BMS design, with a 10 Year Cell Warranty & 5 Year BMS Warranty.
Got positive and negative short circuit protection on the BMS.
Lemoen high quality and durable BMS got communication with most Inverter manufactures.
Can be Paralleled up to 15 units.
Lemoen 11CM Slim line design that gives the least obstruction.
1C charge and discharge rate.
Lemoen battery is design for a long service life, beyond 15 years
All-In-One Energy Storage System
The Best Residential Solar SolutionWith the most practical functions, remote diagnosis & upgrade and plug & play connectors, this hybrid inverter helps you economize on the time-consuming installations and maintenance with minimized efforts. Its compact design saves your space, while its slim appearance fits your house aesthetics. In addition, this hybrid inverter can be installed as a pure solar inverter now, and retrofit storage later with the lead-acid battery (Split Application) or our lithium battery (All-in-one Application) and can be easily expanded at any time.
Hybrid Inverter + Batteries (All-in-one ESS)
Easy & Fast Installation: Play and plug connection saves 40% installation time
Compact & Elegant Design: Unique arc design, support All-in-one or split application
Maximized Self-consumption: Less energy using from grid, more from solar power.
Flexible Storage Capacity: Large energy storage capacity up to 25 kWh.
Smart EV Charger Protection: Over Voltage/Over Temperature/Overload//Overall Full Protection
Easy Local & Remote Control: Remote diagnosis & upgrade minimize the effort of time-consuming manual maintenance.
Additional Information
AC INPUT VOLTAGE/FREQUENCY
186 ~ 290Vac/50 or 60Hz
NOMINAL AC POWER
5000W
NOMINAL AC CURRENT
21.7A
THD OF AC CURRENT
<3%
EPS OUTPUT VOLTAGE/FREQUENCY
220Vac/50 or 60Hz, Single Phase
CONTINUOUS OUTPUT POWER (@25C )
5kVA
EPS OUTPUT CURRENT
21.7A
PEAK POWER
1.1 x Pnom, 10 Sec; 1.5 x Pnom, 100ms
POWER FACTOR
~1 (Adjustable from 0.8 Leading to 0.8 Lagging)
WAVEFORM
Pure Sinusoidal Wave
THD OF AC VOLTAGE
<3% with Resistive Load
MAX. PV VOLTAGE
600V
MPPT VOLTAGE RANGE
125~550V
MAX. PV CURRENT
14/14A
MAX. SHORT CIRCUIT CURRENT
17.5/17.5A
STRINGS PER MPP TRACKER
1
NO. OF MPP TRACKERS
2
BATTERY TYPE
Lithium
BATTERY VOLTAGE
40~60V
GALVANIC ISOLATION FOR BATTERY
Yes
BMS COMMUNICATION
CAN
PROTECTION
Over Voltage, Under Voltage, Over Current, Short Circuit, Over Temperature
EURO EFFICIENCY
97.4%
MAX. EFFICIENCY
97.8%
CELL TYPE
LFP
NOMINAL ENERGY
5kWh
MAX. DEPTH OF DISCHARGE
90%
NOMINAL VOLTAGE
51.2V
OPERATING VOLTAGE RANGE
40-58.4V
NOMINAL CAPACITY
100Ah
MAX. CHARGE CURRENT
50A
MAX. DISCHARGE CURRENT
100A
SCALABILITY
Up to 5 modules/25kWh
BATTERY PARALLEL
5 Units
LuxPower SNA 12000 ECO Hybrid Inverter – 12kW Single Phase
The LuxPower SNA 12000 inverter is a high-performance hybrid system tailored for demanding energy needs. It supports multiple power sources including solar, grid, and generator input, and delivers up to 12kW output power with exceptional charging and discharging capabilities.
Key Features:
12kW continuous power output – ideal for off-grid or backup
Max. 24kW PV input with dual MPPTs
250A max charging/discharging current
Compatible with lithium-ion and lead-acid batteries
Supports AC & generator input with auto start/stop
Force wake battery from PV, grid or generator
Supports up to 16 inverters in parallel
LCD display with Wi-Fi, RS485, and CAN communication
Specifications:
Model
SNA 12000 ECO Hybrid
Rated Output Power
12,000W
Max. PV Input Power
24,000W
MPPT Inputs
2 MPPTs / 4 Strings
MPPT Voltage Range
120V – 385V
Battery Voltage
48V / 51.2V
Battery Voltage Range
46.4–60V (Li-ion), 38.4–60V (Lead-Acid)
Max Charge/Discharge Current
250A
Max Charge/Discharge Power
12,000W
Grid Input Voltage
90V – 280V
AC Output Voltage
230V
Surge Power
Up to 2x (5s duration)
Efficiency
Max: 93.5%, MPPT: 99.0%
Communication
RS485, Wi-Fi, CAN
Display
LCD + RGB
Dimensions (W x H x D)
530 × 830 × 150 mm
Weight
40kg
Protection Rating
IP20
Cooling
Smart cooling
Warranty
2 Years
DATASHEET
Description
General Data• 2 MPPT with 4 Strings, Maximum 24kW PV input• Maximum Charging / Discharging Current 250A• Off-Grid application with 12kW Output Power• Dual AC Ooutput Ports for multiple load connections• Integrated Load and Battery Breaker• PV, AC & Generator wake up Battery• Supports up to 16 Units in Parallel• Dedicated Generator Port• Up to 19.2kW Gen / AC Coupling Input• Auto Generator Start and Stop control
Lux Power 5KW OFFGRID Inverter (SNA5000WPV)
Description
Applicable for pure off grid/ backup power / self-consumption / on grid situation
Integrated with 2 MPPT solar charge controllers, MPPT ranges 120V~385V
Rated power 5KW, power factor 1
Be able to run with or without battery in Ongrid and Offgrid mode
With separated generator input interface, able to control generator remotely
Solar and utility grid can power loads at the same time
With integrated advanced parallel function, up to 9 pcs max paralleling
Support CAN/RS485 for Li-ion battery BMS communication
WIFI/ GPRS remote monitoring , setting and firmware update, support website, free IOS/Android APP
DATASHEET
MANUAL
WIFI SETUP
BMS - SHOTO
BMS - DYNESS
BMS - PYLONTECH
Designed for families seeking reliable and affordable all-in-one energy storage. With remote monitoring and customizable energy setups, you’re in control. And it’s not just smart—it’s simple. Installation is a breeze, taking less than 15 minutes.
Simply plug & play to reduce your grid dependency and energy costs.Luxpower’s XBP-Battery Pack, featuring our renowned Eco-hybrid inverter coupled with low-voltage batteries, liberates you from grid uncertainties and fluctuating energy costs.
Unlocking the
future of energy!
Efficiently harness more sunlight with its high-capacity PV current handling, smartly allocating power for immediate use or storing it for later. Our user-friendly monitoring interface puts control at your fingertips. Plus, rest assured with a backup generator ensuring uninterrupted power during night-time outages.Harness the power of the sun, keeping your home aglow at night and ready for unexpected outages. Intelligently manage your energy mix with advance off-grid and Eco-hybrid modes, empowering your household while decreasing reliance on the grid. Take charge of your energy consumption to conquer peak rates, slash those electric bills, and unleash the full potential of your solar system.
Simplify your monitoring experience
With our platform, gain real-time insights, remote management capabilities,
and seamless control over your devices. Make informed decisions and
optimize performance effortlessly.
Luxpower Off-Grid Pure Sine Wave Inverter (SNA6000) - 6Kw / 6000W / 48V / MPPTThe Luxpower 6kW Eco Hybrid Inverter SNA6000 suits both on-grid and off-grid solar systems. With a 6kW output power and compatibility with up to 16 units in parallel, it's a robust choice for larger installations.The Luxpower 6kW Eco Hybrid Inverter SNA6000 supports various lithium batteries and includes a built-in MPPT solar charge controller.SpecificationsModel: SNA 6000Output Power: 6kWInput (PV DC): 6000WMax. PV Array Power: 8000W (4000/4000)Rated PV Input Voltage: 320VNumber of Independent MPPT Inputs: 2PV Input Voltage Range: 100 / 480VMPPT Voltage Range: 120 / 385VStart-Up Voltage: 100VMax. PV Input Current per MPPT: 17/17AMax. PV Short-Circuit Current Input per MPPT: 25/25AWarranty: 2 YearsCooling Method: FanDimensions: 330x505x135mmWeight: 14.5kgDATASHEET
Luxpower 12kW Hybrid Single Phase Inverter (LXP-LB-EU 12K)Product DescriptionThe Luxpower 12kW Hybrid Single Phase Inverter LXP is a powerful, flexible, and reliable solution designed for residential and commercial solar energy systems. Built with advanced hybrid technology, this single-phase inverter combines solar PV, battery storage, and grid power to deliver uninterrupted energy and maximum efficiency.With its high PV input capacity of up to 18kW, the Luxpower 12kW Hybrid Single Phase Inverter LXP supports 3 MPPT trackers, ensuring optimal solar harvesting even in challenging conditions. The inverter operates seamlessly in on-grid, off-grid, and backup applications, making it suitable for diverse energy needs.Its 12kW UPS-rated output provides reliable backup during load-shedding or grid outages, while the integrated generator interface ensures compatibility with additional power sources. The inverter’s AC coupling function allows easy integration with existing solar systems, while its parallel capability (up to 10 units) enables scalability up to 120kW.Equipped with a 250A charge/discharge current, it supports both Lithium-ion and Lead-Acid batteries with a 48V system, offering fast charging and discharging for improved energy independence. The unit is IP65-rated for outdoor durability and comes with a touchscreen LCD for user-friendly operation and remote monitoring via Wi-Fi, RS485, or CAN.Whether for residential backup, small business operations, or larger energy projects, the Luxpower 12kW Hybrid Single Phase Inverter LXP ensures efficiency, flexibility, and reliability, delivering true energy freedom.Key Features
12kW single-phase hybrid inverter with seamless UPS backup
Supports up to 18kW PV input with 3 MPPTs for maximum efficiency
250A charge/discharge current for fast battery cycling
Compatible with Lithium-ion and Lead-Acid 48V batteries
AC coupling support for easy integration with existing solar systems
Parallel capability – connect up to 10 units for 120kW total output
Smart load control and generator interface included
Touchscreen LCD display with Wi-Fi/RS485/CAN monitoring
High efficiency: 99% MPPT efficiency, 97.5% EU efficiency
Durable outdoor design – IP65 rated, fan cooling system
Rapid shutdown compliant with NEC safety standards
Technical Specifications
Max PV Input Power: 18,000W
MPPT Voltage Range: 120–480V
Max PV Input Current: 25A / 15A / 15A (3 MPPTs)
Battery Voltage: 48V (40–60V range)
Max Charge/Discharge Current: 250A
UPS Output: 12kW / 11.5kW rated
AC Voltage/Frequency: 230V, 50/60Hz
Switching Time: <20ms (seamless backup)
Surge Power: 2Pn, 0.5s
Dimensions: 490 × 670 × 265 mm
Weight: 50kg
Protection: Overcurrent, anti-islanding, short-circuit, leakage, surge, grid monitoring
Warranty: 5 years
A pack of 1x Male and 1x Female cable couplers
(including insulating part)
Snap-in lock
Locking by safety lock clip PV-SSH4 in accordance with NEC 2011, can be released only with tool
Proven MULTILAM technology with high long-term stability, which ensures consistently low performance loss throughout the entire service life of the plug connector
Tried and tested plug connectors, 14 years of experience in the field
Suitable for assembly with cross-sections of 4 and 6 mm²
Rated current: 39 A (for 4 and 6mm2 cable)
Rated voltage: 1000 V IP Rating: IP65 / IP68 when mated (1h / 1min) Cross section: 4 - 6 mm² Outer diameter cable (dA): 5,5 - 9 mm
Please use correct MC4 approved tools to crimp these connectors on to bare cables.
DATASHEET
INSTALLATION MANUAL
General Data• IBR-XH Short Rail Bracket Size: 300mmL x 40mmW x 60mmH• Compatible with IBR and Corrugated Zinc Tiles• Landscape Mountable• Slotted Bracket base allows for easy Flap adjustment to fit IBR profile• Rubberized Flaps ensure a water tight seal once fastened• Long lasting components for South African climate
Kit Contents• 1 x Aluminum Bracket Body• 2 x Stainless Steel EPDM Rubberized Flaps ( EPDM has a 20year life span )• 4 x 6.3x25mm Self Tapping Hexagonal Washer-Head Stainless Steel Screws
Shoto: 5.12Kwh Lithium Battery RM
16 cell 51.2V 100A
Description
The modular and scalable design allows it to be expanded to meet future energy requirements
More than 5000 cycles with 90% DOD and 10+ years design life
Compatible with the most universal hybrid inverters
Simple rack mounted structure to reduce the installation time and cost
DATASHEET
MANUAL
TECHNICAL/CERT
