Newly Updated 1C Batteries
General Data
• Battery Type: LiFePO4
• Total Storing Energy: 5.12KWH
• Voltage Range: 44.8~57.6
• Battery Voltage: 51.2V
• Battery Capacity: 100AH
• Battery System Charge Voltage: 54VDC
• Battery Standard Working Current: 50A
• Battery Normal Working Current: 50A
• Battery Maximum Working Current: 75A
• Battery Discharge Lower-Voltage: 42VDC
• Discharge Condition: -20°C to 55°C
• Charge Condition: -5°C to 55°C
• Battery Module Cell Quantity in Series (pcs) (16)
• Enclosure Protection: IP20
• Wall mount and Rackmount
DATASHEET
MANUAL
BMS SETUP:
Victron
Deye / Sunsynk
Sofar
SMA
Growatt
Additional information
| Weight | 50 kg |
|---|---|
| Dimensions | 55.8 × 54.5 × 19 cm |
Specifications
- Max Load: Max Load
- Usage: Indoor & outdoor
