Increase your solar energy output with the JA Solar 590W N-Type Bifacial Mono Solar Panel. The N-Type technology and bifacial design allow for maximum energy absorption, while the mono construction ensures durability. Harness the power of the sun with this high-performance solar panel.

Certifications

• IEC61215, IEC61730, UL61215, UL61730
• ISO9001:2015: Quality Management System
• ISO14001:2015: Environment Management System
• ISO45001:2018 Occupational health and safety management systems
• IEC 62941: 2019 Terrestrial photovoltaic (PV) module - Quality system for PV module manufacturing.

Features

• High Power Generation, better LCOE
• Better Temperature Coefficient
• N-Type with very low LID
• Low Irradiance response

Superior Warranty

• 12 Year Product Warranty
• 30 Year Linear Power Warranty
• 1% 1st year Degradation
• 0.4% Annual Degradation Over 30 years

Specification

• Model: JAM72D40-590LB
• Cell: Mono
• Weight: 32.5kg
• Dimensions: 2333 x 1134 x 30 mm
• Cable cross section size: 4mm² (IEC), 12 AWG (UL)
• No. of cells: 144 (6x24)
• Junction Box: IP68, 3 Diodes
• Connector: QC 4.10-351 / MC4-EVO2A
• Cable Length (including connectors): Portrait: 300mm (+)/400mm (-) Landscape: 1400mm (+)/1400mm (-)
• Front/Back Glass: 2.0mm/2.0mm

Electrical Parameters at STC

• Rated Maximum Power (Pmax) - 590W
• Open-circuit Voltage (Voc) - 52.00V
• Maximum Power Voltage (Vmp) - 43.41V
• Short-circuit Current (Isc) - 14.35A
• Maximum Power Current (Imp) - 13.59A
• Module Efficiency STC (%) - 22.3%
• Power tolerance - 0~+3%
• Temperature coefficients of Isc - 0.045%/℃
• Temperature coefficients of Voc - -0.250%/℃
• Temperature coefficients of Pmp - -0.290%/℃
• STC: Irradiance 1000Wm² / cell temp 25℃, AM 1.5G

Electrical Characteristics with 10% Solar irradiation ratio

• Rated Max Power (Pmax) - 637W
• Open-circuit Voltage (Voc) - 52.00V
• Maximum Power Voltage (Vmp) - 43.41V
• Short-circuit Current (Isc) - 15.50A
• Maximum Power Current (Imp) - 14.68A

Operating Conditions

• Maximum system voltage: 1500V DC
• Operating Temp: -40°C-+85°C
• Max series fuse rating: 30A
• Max. static load- Front: 5400Pa
• Max. static load- Back: 2400Pa
• NOCT: 45± 2°C
• Bifaciality: 80%± 5%
• Fire Performance: UL Type 29/ Class C
