Livoltek All-In-One 5kW Inverter + 5kWh Battery

Livoltek All-In-One 5kW Inverter + 5kWh Battery

Product form

All-In-One Energy Storage System The Best Residential Solar SolutionWith the most practical functions, remote diagnosis & upgrade and plug &... Read more

Free pickup in our shop(s)

10 in stock Fast delivery

R 46,999.00 Incl. VAT

You may be interested in these products

    • Fast shipping

    Description

    All-In-One Energy Storage System


    The Best Residential Solar Solution
    With the most practical functions, remote diagnosis & upgrade and plug & play connectors, this hybrid inverter helps you economize on the time-consuming installations and maintenance with minimized efforts. Its compact design saves your space, while its slim appearance fits your house aesthetics. In addition, this hybrid inverter can be installed as a pure solar inverter now, and retrofit storage later with the lead-acid battery (Split Application) or our lithium battery (All-in-one Application) and can be easily expanded at any time.

    Hybrid Inverter + Batteries (All-in-one ESS)


    • Easy & Fast Installation: Play and plug connection saves 40% installation time
    • Compact & Elegant Design: Unique arc design, support All-in-one or split application
    • Maximized Self-consumption: Less energy using from grid, more from solar power.
    • Flexible Storage Capacity: Large energy storage capacity up to 25 kWh.
    • Smart EV Charger Protection: Over Voltage/Over Temperature/Overload//Overall Full Protection
    • Easy Local & Remote Control: Remote diagnosis & upgrade minimize the effort of time-consuming manual maintenance.

    Additional Information

    AC INPUT VOLTAGE/FREQUENCY

    186 ~ 290Vac/50 or 60Hz

    NOMINAL AC POWER

    5000W

    NOMINAL AC CURRENT

    21.7A

    THD OF AC CURRENT

    <3%

    EPS OUTPUT VOLTAGE/FREQUENCY

    220Vac/50 or 60Hz, Single Phase

    CONTINUOUS OUTPUT POWER (@25C )

    5kVA

    EPS OUTPUT CURRENT

    21.7A

    PEAK POWER

    1.1 x Pnom, 10 Sec; 1.5 x Pnom, 100ms

    POWER FACTOR

    ~1 (Adjustable from 0.8 Leading to 0.8 Lagging)

    WAVEFORM

    Pure Sinusoidal Wave

    THD OF AC VOLTAGE

    <3% with Resistive Load

    MAX. PV VOLTAGE

    600V

    MPPT VOLTAGE RANGE

    125~550V

    MAX. PV CURRENT

    14/14A

    MAX. SHORT CIRCUIT CURRENT

    17.5/17.5A

    STRINGS PER MPP TRACKER

    1

    NO. OF MPP TRACKERS

    2

    BATTERY TYPE

    Lithium

    BATTERY VOLTAGE

    40~60V

    GALVANIC ISOLATION FOR BATTERY

    Yes

    BMS COMMUNICATION

    CAN

    PROTECTION

    Over Voltage, Under Voltage, Over Current, Short Circuit, Over Temperature

    EURO EFFICIENCY

    97.4%

    MAX. EFFICIENCY

    97.8%

    CELL TYPE

    LFP

    NOMINAL ENERGY

    5kWh

    MAX. DEPTH OF DISCHARGE

    90%

    NOMINAL VOLTAGE

    51.2V

    OPERATING VOLTAGE RANGE

    40-58.4V

    NOMINAL CAPACITY

    100Ah

    MAX. CHARGE CURRENT

    50A

    MAX. DISCHARGE CURRENT

    100A

    SCALABILITY

    Up to 5 modules/25kWh

    BATTERY PARALLEL

    5 Units

    Specifications

    • Max Load: Max Load
    • Usage: Indoor & outdoor
