General Data• IBR-XH Short Rail Bracket Size: 300mmL x 40mmW x 60mmH• Compatible with IBR and Corrugated Zinc Tiles• Landscape Mountable• Slotted Bracket base allows for easy Flap adjustment to fit IBR profile• Rubberized Flaps ensure a water tight seal once fastened• Long lasting components for South African climate
Kit Contents• 1 x Aluminum Bracket Body• 2 x Stainless Steel EPDM Rubberized Flaps ( EPDM has a 20year life span )• 4 x 6.3x25mm Self Tapping Hexagonal Washer-Head Stainless Steel Screws
Shoto: 5.12Kwh Lithium Battery RM
16 cell 51.2V 100A
Description
The modular and scalable design allows it to be expanded to meet future energy requirements
More than 5000 cycles with 90% DOD and 10+ years design life
Compatible with the most universal hybrid inverters
Simple rack mounted structure to reduce the installation time and cost
DATASHEET
MANUAL
TECHNICAL/CERT
Solar cables are suitable for the interconnection of various elements of photovoltaic systems. Suitable for fixed installation outside and inside without protection or inside pipes, ducts or similar closed systems High resistance against ozone, U.V. rays, oils and moisture
Single core cables, for photovoltaic and solar system use, elastomeric compound insulted and sheathed. Flame retardant, halogen free, and low smoke flexible cables for fixed laying.
Solar cables are suitable for the interconnection of various elements of photovoltaic systems. Suitable for fixed installation outside and inside without protection or inside pipes, ducts or similar closed systems High resistance against ozone, U.V. rays, oils and moisture
Single core cables, for photovoltaic and solar system use, elastomeric compound insulted and sheathed. Flame retardant, halogen free, and low smoke flexible cables for fixed laying.
Solar MD 14.3kWh SS4143-01
The SS4143 relies on lithium Iron-Phosphate battery for streamlined energy storage. You can use 1 to 6 batteries on the wall during the setup. The Solar MD 14.3kWh features different storage capacities according to user requirements. We can increase capacity through the parallel connection of the batteries. This will enable you to use from14.3kWh to 85.8kWh setup.
SS4143 BATTERY FEATURES
• Excellent safety• High-temperature performance• Long life cycle• High energy density• Stable discharge platform• High charge & discharge rate• Highly efficient
DATASHEET
MANUAL
🔋 Solar MD SS4160 - 16 kWh Advanced LiFePO4 Battery
Key Specifications:
Parameter
Value
Battery Type
LiFePO4 (Lithium Iron Phosphate)
Rated Capacity
16.0 kWh
Nominal Voltage
51.2 V
Voltage Range
44.8 – 55.6 VDC
Nominal Power @ 0.5C
8.0 kW
Max Charge & Discharge Current
157 A
Cycle Life @ 25°C
≥ 7000 cycles
Charging Efficiency
99%
Operating Temperature
0°C to 50°C
Weight
118 kg
Dimensions (W x D x H)
674 mm x 187 mm x 606 mm
Storage Duration
6 months @ 25°C
Certifications & Compliance:
CE / EN 55016 / IEC 61000
IEC 62619 / UN38.3 / UN3480
UL 1642 / UL 1973
Features:
Modular design (parallel scalable)
Wall or floor mounted
High energy density
Long life cycle
Stable discharge
High charge/discharge rate
Built-in Battery Management System (BMS)
CANBUS & RS485 Communication
Compatible with:
Deye
McRockage
Sunsynk
Sungrow
Goodwe
Sermatec
Huawei
BMS Functions:
Cell balancing
Overcharge/discharge protection
Temperature monitoring
SOC calculation & control
Data logging & storage
Communication via CANBUS, RS485
EMS Integration (mypower24 platform):
Real-time data & insights
Remote management
Secure communication
Integrated with Logger V2
SRNE 10kW Off-Grid Inverter.The SRNE 10kW Off-Grid Inverter is a powerful and efficient solution for powering your home or business independently of the grid. It’s designed to convert DC power from solar panels into usable AC power.
Key Features
Battery Compatibility: Supports a wide range of battery types.
Pure Sine Wave Output: Delivers clean, stable AC power.
High Power Output: Rated output of 10,000W and a peak power of 20,000W.
Protection Features: Equipped with overvoltage, undervoltage, overload, and short-circuit protection.
Remote Monitoring: Wi-Fi modules for real-time monitoring of your system’s performance
Specifications:
Inverter Output:
Rated Output Power: 10,000W
Max.Peak Power: 20,000W
Rated Output Voltage: 230Vac（single-phase L/N/PE ）
Switch Time: 10ms（typical）
Battery:
Battery Type: Li-ion / Lead-Acid / User Defined
Rated Battery Voltage: 48Vdc
Voltage Range: 40～60Vdc
Max.MPPT Charging Current: 200A
Max.Mains/Generator Charging Current: 120A
Max.Hybrid Charging Current: 200A
PV Input
Num. of MPP Trackers: 2
Max.PV array power: 5,500W + 5,500W
Max.input current: 22A + 22A
Max.Voltage of Open Circuit: 500Vdc + 500Vdc
MPPT Voltage Range: 125～425Vdc
General
Dimensions: 620*445*130mm
Weight: 27kg
Noise: <60dB
Cooling Method: Internal Fan
Warranty: 2 Years
Discover the power of the SRNE 5Kw Off Grid inverter – robust, efficient, and perfect for home use. Designed by SRNE Solar, this cutting-edge inverter features Rated Power of 5,000W and a Max. Peak Power of 10,000VA. Moreover, its single MPP tracker ensures seamless solar energy management. Furthermore, this inverter is compatible with both Li-ion and Lead-acid batteries, offering flexibility for various energy storage setups.
In spite of its impressive capabilities, the SRNE 5Kw Off Grid Inverter remains easy to use and, most importantly, safe for your home. In addition, it’s designed to deliver consistent power output throughout its lifetime.For those seeking even greater power capacity, consider the SRNE 10Kw Off Grid Inverter. Alternatively, the Luxpower 5Kw Off Grid Inverter is another excellent choice that presents similar features.
Model: HYP4850S100-H.Manufacturer: SRNE Solar.
INVERTER OUTPUT
Rated Power: 5,000W.
Max. Peak Power: 10,000VA.
Rated Output Voltage: 230Vac (L/N/PE single-phase).
Load Capacity of Motors: 4HP.
Rated AC Frequency: 50/60Hz.
Waveform: Pure sine wave.
Switch Time: 10ms (typical).
Parallel Capacity: 1-6 units (single/three phase).
BATTERY
Battery Type: Li-ion / Lead-acid and user-define.
Rated Battery Voltage: 48Vdc.
Voltage Range: 40-60Vdc.
MPPT Charging Current: 100A.
Mains/Generator Charging Current: 60A.
Hybrid Charging Current: 100A.
PV INPUT
Num. of MPP Trackers: 1.
Max. PV array power: 5,500W.
Input current: 22A.
Voltage of Open Circuit: 500Vdc.
MPPT Voltage Range: 120-450Vdc.
GENERAL
Dimensions: 446.9*350*133 mm.
Weight: 13kg.
Noise: <60dB.
Warranty: 2 years.
COMMUNICATION.
Embedded Interfaces RS485/CAN/USB/dry contact.
External Modules (Optional) Wi-Fi/GPRS.
Sunsynk 10.24kWh Lithium-ion Battery (LiFeP04)
USABLE POWER: (10.24kWh) 100% DOD
Sunsynk have produced a great storage solution to be combined with Sunsynk inverters. The battery can be expected to remain serviceable for more than 10 years with a daily cycle at room temperature (25°C). The Sunsynk Lithium ferro phosphate batteries provide excellent thermal stability and storage for peace of mind. The Sunsynk LFP battery also incorporates a self-monitoring function for the detection of any abnormalities in power storage.The Sunsynk 5.12kWh battery is an excellent quality battery with backup, excellent technical support and is ideal for solar systems and backup power.
SPECIFICATIONS
Capacity – 10.24Kwh / 200Ah / 51.2V
Standard charge current - 100A (1C)
Maximum continuous charge / discharge current - 200A (1C)
Maximum Pulse output current - 400A (1C) (Peak Inrush Current)
6000 cycles (at 25c) with 80% DoD
Modular design for system scalability
Built in BMS that protects the cells from abnormal temperature, current, voltage, Short circuit, SoC and SoH.
Communication: Sunsynk | Deye - CAN & RS485
Up to 8 Batteries in Parallel
Operating Temperature > -20 to 55 degrees celsuis. (ideally 25 degrees C) (Max Operating Temp 55 degrees)
FINISHING:
Powder coated - White/Cream
DIMENTIONS (mm):
550×160×836mm 90KG
MOUNTING:
Wall mounted - Wall Bracket Included
WARRANTY:
10 Years - (25 degrees C)Terms & Conditions apply.
DATASHEET
The Sunsynk 12kW Single Phase Inverter are designed to work with both solar panels and battery storage systems, allowing you to generate and store electricity from solar energy. Efficiently harness solar energy with the Sunsynk 12kW Single Phase Inverter, designed for seamless battery storage integration. INTERACTIVE– Easy and simple to understand display– Supporting Wi-Fi or GSM monitoring– Visual power flow screen– Smart settable 3-stage MPPT charging for optimized battery performance– Auxiliary load function– Parallel / multi-invert function grid-tied and off-gridCOMPATIBLE– Compatible with main electrical grid voltages or power generators– Compatible with wind turbines– Self-consumption and feed-in to the grid– Auto restart while AC is recovering– Auto earth bond feature (Via a relay)CONFIGURABLE– Fully programmable controller– Programmable supply priority for battery or grid– Programmable multiple operation modes: on-grid/off-grid & UPS– Configurable battery charging – current/voltage based on applications by LCD setting– Configurable AC / solar / generator charger priority by LCD settingSECURE– Overload/over-temperature/short-circuit protection– Smart battery charger design for optimized battery protection– Limiting function installed to prevent excess power overflow to the gridAPPLICATIONS– Marine (vessel power management)– Power shedding (home/office/factory)– UPS (fuel-saving systems)– Remote locations with solar and wind generators– Building sites– Military locations– Telecommunication
