Top benefits
Up to 4.2× efficiency (COP ≈ 420%) – ~4.2 kW heat from ~1 kW electricity
Solar-first, grid-assist – works without an inverter or batteries
Smart control – Built-in MPPT, Wi-Fi/Bluetooth app, timers & power limiter
Why this heater?
Massive energy savings – Harvests ~3.2 kW from ambient air + sun for every ~1 kW drawn.
True daytime independence – Runs directly from PV; no inverter or battery required.
Always-on hot water – Seamless AC assist at night or in low-sun conditions.
Built-in intelligence – Integrated MPPT (≈99.8% tracking), one-touch AC limiter, real-time power monitoring, and scheduling.
All-season performance – Designed to heat reliably in both low and high ambient temperatures.
Safer by design – PV lightning protection, residual current monitoring, over-current & over-voltage protection.
Versatile applications
Domestic hot water (homes, flats, guesthouses)
Underfloor heating (low-temp circuits)
Pools & spas (extend your swimming season)
Small commercial use (offices, gyms, salons)
Smart control & connectivity
Wi-Fi & Bluetooth app control
Live energy tracking (see PV vs grid contribution)
Timers for low-tariff windows and comfort schedules
Key specs
Capacity: 200 L
Type: Solar air-source heat pump (hybrid AC/DC)
Efficiency: COP up to ~4.2 (≈420%)
Controller: Built-in solar MPPT (≈99.8% tracking)
Power modes: Solar direct (day), Grid assist (night/low sun)
Safety: PV surge protection, RCD monitoring, over-current/over-voltage
Connectivity: Wi-Fi / Bluetooth; app monitoring & control
What’s in the box
Deye 200 L Solar Air-Source Water Heater (AC/DC)
Integrated MPPT solar controller
User manual & quick-start guide
Installation notes (recommend)
Professional installation required by a qualified plumber/electrician.
Position for good airflow and sun exposure; follow PV string/voltage guidelines.
Add isolators, drip tray & safety valves per local regulations.
Mini-FAQ
Q: Will it work during load-shedding?A: Yes—during the day it can run directly from PV. At night or low-sun it can draw limited AC from the grid as needed.
Q: Do I need an inverter or batteries?A: No inverter/batteries required. It’s designed to connect directly to solar PV and can use grid AC as backup.
Deye 20kW Hybrid – 3 Phase Inverter Features
Three Phase – High Voltage
Colourful Touch LCD Screen
Max Charging/Discharging Current of 50A
Parallel up to 10 Units
Compact & Stylish
Safe and Easy Installation
5-year warranty
Set system parameters remotely with FREE SOLARMAN PRO App
If installed with a Deye battery, the warranty on the inverter will increase to 10 Years.
This Deye 20kW Hybrid Inverter is a 3 Phase inverter which must be paired with a high voltage battery bank.
Deye is renowned for its reliable and safe products, ensuring continued productivity in the commercial sector with the use of Solar Power and battery backup (sold separately).
The Deye 20kW Hybrid Inverter is user-friendly and equipped with an intelligent monitoring platform, allowing you to shut down immediately in the event of an accident remotely. The Smart Monitoring Platform allows users to quickly and remotely set parameters and perform firmware updates.
The versatility of this inverter is amazing, you can:
Use it like a Grid-Tied, with panels only
Use it as a Load Shedding Solution, with batteries only
Use it in an Off-Grid situation, not connected to the grid
Use it in an On-Grid situation, connected to the grid
Use it as a UPS (Uninterrupted Power Supply)
Use it for Commercial purposes due to it’s Robust build
10-Year warranty is paired with Deye batteries
You can parallel 10 inverters to create a huge Solar System, ideal for commercial applications.
General Data• 100% Unbalanced Output per phase, Max. Output up to 50% rated power• AC-Couple to retrofit existing Solar System• Parallel up to 10 Units for On-Grid and Off-Grid operation• Support multiple Batteries in Parallel• Maximum Charging / Discharging Current of 350A• 48V Low Voltage Battery, transformer isolation design• 6 time periods for Battery Charging / Discharging• Support storing energy from Diesel Generator
PLEASE NOTE: SOLAR PANELS NOT INCLUDED.
Description
100% energy saving in day time. Only solar panel drive.
T3 Compressor
AC grid power limiter, limit AC power from 0-600W
AC power mode, DC power mode, AC+DC mix power supply (AC/DC Auto Balance)
No inverter, no battery, no charge controller
Full DC driven
Wide operating temperature (-10℃ to 58 ℃)
Long warranty years
Deye hybrid ACDC solar air conditioners require no batteries, and only a few PV panels to deliver huge savings. Duringthe day, when air conditioning is needed the most, you can operate this unit partly or up to 100% by it’s independent solarpanels to achieve maximum efficiency. At night, you can continue to save due to it’s high efficiency.The WIFI functionality allows full control, daily and weekly timers, complete visibility with AC and DC consumption andthe history of all power consumption.
Advised Solar Panel: (3 – 8)* 330W in series
Dimensions & Certification
Net weight indoor: 15Kg
Net weight outdoor: 48.5Kg
Net size indoor (mm): 1085 x 330 x 239
Net size outdoor (mm): 700 x 900 x 337
DEYE 300L Solar Air-Source Water Heater (AC/DC)
Bigger tank. Same ultra-efficient, solar-first heating.
Top benefits
Up to 4.2× efficiency (COP ≈ 4.2) – ~4.2 kW heat from ~1 kW electricity
Solar-first, grid-assist – runs directly from PV by day; seamless AC backup at night/low sun
Smart control – Wi-Fi/Bluetooth app, schedules, weather-adaptive heating, grid power limiter
Why this heater?
Large 300 L capacity – great for bigger families, guesthouses, or light commercial use.
Real energy savings – extracts free heat from ambient air + sun to slash electricity costs.
Daytime independence – operates on DC solar with no inverter or batteries required.
Always-on hot water – auto-switches to grid AC when needed, with solar as priority.
Intelligent comfort – weather compensation adjusts target temps to avoid wasted energy.
Safer by design – PV lightning protection, residual-current monitoring, over-current/over-voltage protection.
Smart control & monitoring
Deye Smart App (Wi-Fi/Bluetooth): set temps, view power usage, schedule heating.
Grid AC Power Limiter: one-touch cap on grid draw to manage costs.
Versatile applications
Domestic hot water (homes, apartments, B&Bs)
Underfloor heating (low-temp circuits)
Pools & spas (extend the swim season)
Offices, gyms, salons (light commercial)
Key specs (quick view)
Capacity: 300 L
Type: Solar air-source heat pump (hybrid AC/DC)
Efficiency: COP up to ~4.2
Power modes: Solar direct (day), Grid assist (night/low sun)
Controls: App (Wi-Fi/Bluetooth), timers, weather compensation, AC limiter
Safety: PV surge protection, residual current monitoring, over-current/over-voltage
What’s in the box
Deye 300 L Solar Air-Source Water Heater (AC/DC)
Integrated solar control electronics
User manual & quick-start guide
Installation notes (recommend)
Professional install by qualified plumber/electrician.
Site for good airflow and PV exposure; include isolators and safety valves per local regs.
Confirm PV string sizing and cable protection to spec.
Mini-FAQ
Q: Does it work during load-shedding?A: Yes. It can run off PV during the day; at night/low sun it uses limited AC as backup.
Q: Do I need an inverter or batteries?A: No. It’s designed to connect directly to solar PV and can use grid AC when needed.
Q: Is 300 L right for me?A: Choose 300 L for 4–7+ users, guest suites, or light commercial. For 2–4 users, consider the 200 L model.
Revolutionize Your Energy: Deye 30KW Three-Phase Hybrid Inverter. Maximize solar efficiency with the Deye 30KW Hybrid Inverter featuring dual MPPT trackers and battery storage for robust energy management.
Features
Grid-tied, off-grid, and backup power capabilities.
Model: SUN-30K-SG01HP3-EU.
Max DC Input Power: 39000W.
Max DC Input Voltage: 1000V.
Start-up Voltage: 180V.
MPPT Voltage Range: 150-850V.
Rated DC Input Voltage: 600V.
Compatible with a variety of Batteries – HV (High Voltage)
5-year warranty.
DEYE Inverter with DEYE Battery qualified for a 10 year warranty on both.
◆SaferCobalt FreeLithium Iron Phosphate (LFP) Battery: Safety andlong l ifespan, high efficiency and high p ower density.Intelligent BMS, providing complete protection.◆ReliableSupporthigh discharge power. IP20, natural cooling, widetemperature range: 20 to 55◆FlexibleModulardesign, easy to expand, Max. 64 units in parallel,Max. capacity of 3 40 kWh.Suitedto residential and commercial applications for increasingthe self consumption ratio.◆ConvenientBattery module auto networking,e asy maintenance, supportremotely monitoring and upgrade, s upport USB drive upgradethe firmware.◆EcoFriendlyUseenvironmental protection materials, the whole modulenon toxic, pollution free
This lithium iron phosphate battery is one of new energy storage products developed and produced by DEYE, it can be used to support reliable power for various types of equipment and systems. This battery is especially suitable for application scene of high power, limited installation space and long cycle life. This battery has built-in BMS battery management system, which can manage and monitor cells information including voltage, current and temperature. What’s more, BMS can balance cells charging and discharging to extend cycle life. Multiple batteries can connect in parallel for larger capacity and longer power supporting duration requirements.
Description
Battery Input Data• Battery Type: Li-Ion• Battery Voltage Range: 160VDC to 800VDC• Maximum Charging Current: 50A + 50A• Maximum Discharging Current: 50A + 50A• Number Of Battery Input: 2• Charging Strategy for Li-Ion Battery: Self adaption to BMS
PV String Input Data• Maximum DC Input Power: 65000W• Maximum DC Input Voltage: 1000VDC• Startup Voltage: 180VDC• MPPT Voltage Range: 150VDC to 850VDC• Full Load DC Voltage Range: 450VDC to 850VDC• Rated DC Input Voltage: 600VDC• PV Input Current: 36A + 36A + 36A + 36A• Maximum PV (Isc): 55A + 55A + 55A + 55A• No of MPP Trackers: 4• Strings per MPP Tracker: 2
AC Output Data• Rated AC Output and UPS Power: 50000W• Maximum AC Output Power: 55000W• AC Output Rated Current: 75.8A / 72.5A• Maximum AC Current: 83.3A• Maximum Continuous AC Passthrough: 150A• Peak Power (Off Grid): 1.5 time of rated Power, 10S• Generator Input: 75.8A• Smart Load: 150A• AC Couple Current: 75.8A• Power Factor: 0.8 Leading to 0.8 Lagging• Output Frequency and Voltage: 50/60Hz; 3L/N/PE 220/380VAC, 230/400VAC• Grid Type: Three Phase
Environment Limit• Operating Temperature Range: -40°C to 60°C• Cooling: Smart Cooling (<45 dB)• Communication with BMS: RS485 / CAN• Ingress Protection: IP65• Safety Certification: IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
Deye 5kW Hybrid Inverter (New Generation) – Single Phase
The Deye 5kW Hybrid Inverter (New Gen) is a high-performance single-phase inverter built for both on-grid and off-grid solar systems. With support for lithium and lead-acid batteries, this unit is perfect for homes or small businesses aiming to reduce electricity bills, avoid load shedding, or achieve energy independence.
Key Features:
Pure sine wave hybrid inverter
Compatible with lithium and lead-acid batteries
High efficiency with dual MPPTs (Max. 6500W PV input)
Supports generator input and energy storage from diesel generators
Wi-Fi monitoring via mobile app
Color LCD display with IP65 protection rating
6 configurable battery charge/discharge periods
Remote monitoring and firmware updates
Specifications:
Model
SUN-5K-SG04LP1-EU-SM2
Rated Power
5,000W
Max. PV Input Power
6,500W
MPPT Voltage Range
150V – 425V
Battery Type
Lithium-ion / Lead-acid
Battery Voltage Range
40V – 60V
Max. Charge/Discharge Current
135A
Rated AC Output Voltage
230V
Rated AC Output Power
5,000W
Max. Efficiency
97.6%
MPPT Efficiency
>99%
Surge Power
2x rated power (10s)
Cooling
Natural cooling
Noise
< 30dB
Protection Level
IP65
Communication
RS485, CAN, Wi-Fi, optional 4G
Dimensions (W x H x D)
376 × 470 × 241.5 mm
Weight
~19 kg
Warranty
5 Years (extendable)
DATASHEET
Deye 6kW Single Phase Hybrid Inverter – SUN-6K-SG04LP1-EU-SM2
VOC: 500V | Battery: 48V | CT & WiFi Included
Power your home or small business with confidence using the Deye 6kW Single Phase Hybrid Inverter – a versatile, high-performance inverter designed for both on-grid and off-grid solar systems. This smart hybrid solution integrates seamlessly with lithium or lead-acid batteries and allows for energy storage, self-consumption, and grid backup.
✅ Key Features:
High PV Input Power: Up to 8,000W with a max PV input voltage of 500V
Efficient Performance:
Max Efficiency: 97.6%
Euro Efficiency: 96.5%
MPPT Efficiency: >99%
Flexible Battery Compatibility: Works with 48V lithium or lead-acid batteries
High Charging/Discharging Current: Up to 140A
Smart Load Management: 6 configurable time periods for battery charging/discharging
Parallel Support: Connect up to 16 units for on- or off-grid systems
AC Coupling Ready: Ideal for retrofitting existing solar systems
Built-In Monitoring: Includes CT & WiFi module for real-time monitoring via app
User-Friendly Interface: 4.3" colorful touch LCD with IP65 weatherproof protection
🛡️ Built-In Safety & Protection:
DC reverse polarity, AC overcurrent, short circuit, overvoltage, ground fault detection
Type II surge protection (DC & AC sides)
Compliant with global grid and safety standards (IEC, CEI, VDE, NRS, etc.)
📐 Specifications:
Rated Power: 6,000W
Battery Voltage Range: 40–60V
Max PV Input: 8,000W
MPPT Voltage Range: 150–425V
Noise Level: <30dB (natural cooling)
IP Rating: IP65 – suitable for indoor/outdoor use
Weight: 19kg
Size: 376 × 470 × 241.5 mm
🔌 Ideal For:
Hybrid solar systems with battery storage
Load shifting, energy independence, and backup power
Residential or light commercial applications
Product Features
Off-grid Functionality
Colorful touch LCD
IP65 protection degree
Battery Management System (BMS)
AC couple to retrofit existing solar system
Max. 16 pcs parallel for on-grid and off-grid operation
Support multiple batteries parallel
Max. charging/discharging current of 135A
Support storing energy from diesel generator
DATASHEET
Deye 80kW Three-Phase Hybrid Inverter
Engineered for commercial, agricultural, and industrial-scale energy systems, the Deye 80kW Three-Phase Hybrid Inverter offers robust performance, unmatched scalability, and intelligent grid flexibility. This high-voltage inverter is built to manage large energy loads while maintaining maximum system stability — ideal for demanding off-grid, on-grid, or hybrid applications.
With support for up to 10 units in parallel operation, 160A charge/discharge current, and multiple PV and battery configurations, this system is tailored for businesses, solar farms, and energy contractors looking for reliable, efficient storage and grid interaction.
Key Features
Supports 160,000W PV input for large-scale solar installations
Parallel-ready (up to 10 units) for high-capacity systems
Dual battery ports and AC-coupling for legacy system upgrades
100% unbalanced load support per phase – real-world usability
Multi-mode operation (grid-tied, off-grid, or hybrid)
Advanced grid compliance (IEC, CEI, VDE, NRS, G99, and more)
6 programmable battery charge/discharge periods for smart energy shifting
Technical Specifications
Specification
Details
Model
SUN-80K-SG02HP3-EU-EM6
Max PV Input Power
160,000W
Max AC Output Power
80,000W
Battery Compatibility
High-voltage Lithium-ion
Battery Voltage Range
160V – 1000V
Max Charge/Discharge Current
160A
Parallel Units Supported
Up to 10
No. of MPP Trackers / Strings
6 / 12
Max PV Input Voltage
1000V
MPPT Voltage Range
150V – 850V
AC Output Voltage / Frequency
230/400V (3-phase) / 50/60Hz
Max Efficiency / Euro Efficiency
97.6% / 97.0%
MPPT Efficiency
>99%
Noise Level
≤65 dB
Protection Class
IP65
Cooling
Intelligent Air Cooling
Dimensions (W x H x D)
606 x 927 x 314 mm
Weight
97.5 kg
Communication Ports
RS485 / RS232 / CAN / 4G / LAN
Certifications
IEC, CEI, VDE, G99, NRS, and more
Warranty
5 Years Standard (Extendable to 10)
DATASHEET
Deye 8kW Hybrid Inverter New Model with color touch LCD, IP65 rating, supports parallel batteries, and max charging current of 190A.• NEW UPDATED MODEL• Color Touch LCD• IP65 Rating• AC-Couple to retrofit existing Solar System• Maximum 16 PCS Parallel for On-Grid and Off-Grid operation• Support multiple Batteries in Parallel• Maximum Charging / Discharging Current of 190A• 6 time periods for Battery Charging / Discharging• Support storing energy from Diesel Generator
NOTE: If the screen does not come on straight after pluging the unit in, please leave it plugged in and switched on for 24 hours, The screen should now have come on.
PRODUCT DESCRIPTION
Do you ever wonder how much electricity your appliances are using?
The solution is here!
1) Plug the watt meter in-between the wall plug and your appliance
2) Immediately see exactly what your appliance is using (in watts)
Functions:
The watt meter is plug and play. Just plug the cord into an electrical outlet and plug any device (up to 3600W) into the watt meter. If you want to measure multiple devices at once, you can plug an extension cord into the outlet of the watt meter
You can measure the following:
Wattage: 0~3600W (Max 3600 watts)
Voltage
Current: 0-16A (Max 16A)
Power Factor
Electricity Cost
Measure your power usage from the wall with this must have device.
The unit has 7 overall functional modes:1) Real time power usage of an appliance in Watts2) Total power used since monitoring started in Watts3) Real time electrical voltage & frequency4) Real time electrical current & power factor5) Minimum power rating since monitoring started in Watts6) Maximum power rating since monitoring started in Watts7) Cost of total power used since monitoring started (based on set cost per kWh)
Technical Specifications:Operating Voltage: 220-250vAC, 50HzOperating Current: Max 16AWattage Range : 5-3600WCurrent Range : 0.02-16AMeter Power Consumption : 0.5WkWh Cost Range 0-99.99c/kWhTotal kWh Range : 0-9999 KWhTotal Cost Range : 0-9999 CostConnector : 3-pin South African PlugAccuracy : +/- 2%
Includes:1 x Watt Meter1 x User Manual
The Dyness 12.8V 100Ah Lithium Ion Battery delivers reliable energy storage with a capacity of 1.28 kWh, ideal for off-grid and backup power applications. Its advanced lithium-ion technology ensures long cycle life, high efficiency, and stable performance, making it a durable and efficient solution for energy management systems. Compact and lightweight, this battery supports seamless integration into various setups, providing consistent power with enhanced safety features. Perfect for users seeking expert-grade energy storage with dependable output and extended service life.
optimal performance.
Highly efficient with 1.28kWh capacity
Robust design for long-lasting 12v 100ah Lithium Battery power
Compact and energy-efficient
Powerbox Pro
The Powerbox Pro is a type of deep cycle and high capacity lithium battery, support wall-mounted and landed two use modes, the energy can get up to 10kWh for single unit with efficient performance, meet the household electricity demand.
The Powerbox Pro lithium battery provides a good solution for residential electricity consumption. LiFePO4 chemistry battery with safety performance and longer cycle life. Four specifications for your choice which offers you various capacities to meet more of your requirements.
◆APP Monitoring
◆Various Installation
◆IP65 Protection
◆Flexible Expansion
14.3kWh Dyness PowerBrick Battery
The 14.3kWh Dyness PowerBrick Battery is a high-performance energy storage solution engineered for residential applications. Its modular design allows easy integration into various energy storage systems and scalability up to a massive 716.8kWh capacity, making it a versatile choice for households and businesses alike. Leveraging LiFePO4 technology ensures safety, efficiency, and durability for long-term use.
Key Features
Modular and Scalable Design
Expandable from 14.3kWh up to 716.8kWh without requiring a HUB, offering flexibility for future energy needs.
Advanced LiFePO4 Technology
Ensures maximum safety, reliability, and extended cycle life compared to traditional battery chemistries.
Compact and Efficient
24% size reduction and 40% capacity increase compared to previous generations, optimizing space utilization.
High Power Output
200A continuous discharge current and a maximum power of 10kW, capable of handling high-demand applications.
Unlimited Cycles & 10-Year Warranty
Designed for unlimited cycles, guaranteeing peace of mind and exceptional value over a decade.
