Description
Newly Updated 1C Batteries
General Data• Battery Type: LiFePO4• Total Storing Energy: 5.12KWH• Voltage Range: 44.8~57.6• Battery Voltage: 51.2V• Battery Capacity: 100AH• Battery System Charge Voltage: 54VDC• Battery Standard Working Current: 50A• Battery Normal Working Current: 50A• Battery Maximum Working Current: 75A• Battery Discharge Lower-Voltage: 42VDC• Discharge Condition: -20°C to 55°C• Charge Condition: -5°C to 55°C• Battery Module Cell Quantity in Series (pcs) (16)• Enclosure Protection: IP20• Wall mount and Rackmount
DATASHEET
MANUAL
BMS SETUP:
Victron
Deye / Sunsynk
Sofar
SMA
Growatt
Additional information
Weight
50 kg
Dimensions
55.8 × 54.5 × 19 cm
DL5.0C
DYNESS DL5.0C adopts economic design, and is tailor-made for residential & small commercial application. This LFP battery module supports remote update and APP monitoring,and provides multiple installation methods. It is scalable from 5.12 -256 kWh (max. 50 modules in parallel), providing various energy storage options to meet different requirements.
Model DL5.0C
Battery Type LiFePO4
Nominal Battery Energy 5.12 kWh
Nominal Capacity 100Ah
Nominal Voltage 51.2V
Operating Voltage 44.8 ~ 57.6V
Recomended Charge & Discharge C Rate 0.5C
Maximum Discharge C rate 1C
Recommended Charge/Discharge Current 50A
Max Continous Charge Current 75A
Max Continous Discharge Current 100A
Peak Power Charge/Discharge Current 110A (15s)
Depth of Discharge (DOD) 90%
Net Weight 54 kg
Dimension[W*D*H] 558*545*150 mm
Charging Temp. Range 0~55℃
Discharging Temp. Range -20~55℃
Communication CAN/RS485/RS232
Cycle Life[1] ≥6000 Cycles
Protection Level lP20
Expansion up to 50 units in parallel
Pros Can be used in both off-grid and hybrid setups, compact design
Certification & Safety Standard UN38.3/CE-EMC/IEC62619/CEI-021 all undergoing
[1]Test conditions: 0.2C Charging/Discharging, @25℃, 80% DOD
Description
General Data• Generator Connectivity with multiple Input Methods and Automatic Generator On/Off Control• Automatic UPS Switching <4ms• Supports Peak Shaving Control in both “Self-Use” and “Generator” Modes• 6 customizable Charge / Discharge time settings• 10 second 200% Surge Power backup overload capability• Supports 1ph and 3ph Flexible Connection with Max 36kW (5.0/6.0K) and 48kW (8.0K) in Parallel• Up to 135A (5.0/6.0K) and 190A (8.0K) Max Charge / Discharge Current• City Of Cape Town Approved
Description
General Data• Generator Connectivity with multiple Input Methods and Automatic Generator On/Off Control• Automatic UPS Switching <4ms• Supports Peak Shaving Control in both “Self-Use” and “Generator” Modes• 6 customizable Charge / Discharge time settings• 10 second 200% Surge Power backup overload capability• Supports 1ph and 3ph Flexible Connection with Max 36kW (5.0/6.0K) and 48kW (8.0K) in Parallel• Up to 135A (5.0/6.0K) and 190A (8.0K) Max Charge / Discharge Current• City Of Cape Town Approved
Description
General Data• Generator Connectivity with multiple Input Methods and Automatic Generator On/Off Control• Automatic UPS Switching <4ms• Supports Peak Shaving Control in both “Self-Use” and “Generator” Modes• 6 customizable Charge / Discharge time settings• 10 second 200% Surge Power backup overload capability• Supports 1ph and 3ph Flexible Connection with Max 36kW (5.0/6.0K) and 48kW (8.0K) in Parallel• Up to 135A (5.0/6.0K) and 190A (8.0K) Max Charge / Discharge Current• City Of Cape Town Approved
Description:The E-GO Badger is engineered for strength. With dual motors and superior torque, it handles steep inclines and heavier loads with ease.
✅ Key Features:
Motor system for powerful hill climbs
High weight capacity
Sturdy, reinforced frame
Long-range battery for extended rides
DATASHEET
Description:The E-GO Buffalo is a workhorse built for strength and endurance. Designed for tough conditions, it’s the ideal scooter for rural or off-road use.
✅ Key Features:
Rugged all-terrain tires
High torque motor for rough surfaces
Extra durable frame
Long battery life for extended journeys
DATASHEET
Description:The E-GO Cheetah is the flagship model, combining premium design, high speed, and advanced safety features. Perfect for riders who want the best in electric scooter technology.
✅ Key Features:
Top-tier speed and performance
Advanced suspension system
Longest range in the E-GO lineup
Sleek, premium design with safety enhancements
DATASHEET
E-GO Impala Electric Scooter – Long Range Power and Durability
The E-GO Impala Electric Scooter is designed for riders who value performance, comfort, and reliability. Whether you’re commuting through the city, navigating suburban streets, or exploring mixed terrains, this scooter combines long-range endurance with robust construction to deliver a superior riding experience.
Powered by an 800W motor and a 48V 10.4Ah battery, the E-GO Impala Electric Scooter reaches speeds of up to 45 km/h with an impressive range of 35–45 km on a single charge. With a charging time of just 5–6 hours, you’ll always be ready for your next ride without long waits. Built for versatility, it confidently handles inclines of up to 25°, making it suitable for both urban commutes and light off-road adventures.
The Impala is constructed from durable aluminium alloy for strength without unnecessary weight. Its front and rear suspension system, along with 10-inch off-road tires, ensures smooth handling and excellent shock absorption across varied surfaces. For safety and control, the scooter is equipped with front and rear disc brakes, LED front and rear lights, indicators, and a built-in NFC card key system for secure access.
Practicality is a top priority with the Impala L12. It’s built with a 150 kg max load capacity, IP55-rated water resistance, and a compact package size for transport and storage. The optional seat adds extra comfort for longer rides, while the RSA charger ensures easy and reliable recharging.
Key Features:
Powerful 800W motor with strong acceleration and hill-climbing ability
Extended 35–45 km range for longer commutes and weekend rides
Durable aluminium alloy frame with IP55 waterproof rating
Advanced braking system with front and rear disc brakes
10” off-road tires and dual suspension for smooth, stable rides
150 kg load capacity to suit a wide range of riders
Secure NFC key access with optional seat for added comfort
The E-GO Impala Electric Scooter is more than just a ride—it’s a dependable partner for commuting, leisure, and adventure. Combining performance, safety, and durability, it redefines what an e-scooter can deliver.
DATASHEET
The E-GO Meerkat is designed for smooth and efficient city rides. Compact, portable, and energy-efficient, this scooter is perfect for short daily commutes and navigating busy streets.
✅ Key Features:
Lightweight frame for easy carrying and storage
Long-lasting battery with quick recharge
Smooth handling for urban environments
Low maintenance, eco-friendly design
DATASHEET
Description:The E-GO Rhino delivers maximum power and acceleration. With its aggressive performance and durable build, it’s built for experienced riders seeking speed and control.
✅ Key Features:
Extreme torque for rapid acceleration
Heavy-duty build for stability
Long-range high-capacity battery
Premium braking system for safety
DATASHEET
Description:Built for adventure, the E-GO Springbok delivers speed and power on and off the road. Its rugged design and strong motor make it the ideal choice for thrill-seekers.
✅ Key Features:
High-torque motor for fast acceleration
Off-road tires for rugged terrains
Long-lasting lithium battery
Sturdy frame for stability at high speeds
DATASHEET
60W LED (110lm per Watt), 9Ah 12V Battery, SolarPanel 9W/5V, *10hours Charge Time,12-16hours Discharge Time,PIR Sensor (6-8 Meters Detection Area),Work Temp -20°C to 45°C, 80 Square MetersIllumination Area, ABS Plastic + PC Lens, IP65,
*POLE EXCLUDED
L:395xW:210xH:50mm
Description
3M INSTALLATION HEIGHT,*COOL WHITE (±6500K), ABS PLASTIC
SUITABLE FOR WALL OR POLE INSTALLATION
This product is made up of integrated parts (solar panel, lithium battery, LED, MPPT controller)
Can be installed in gardens, residential areas, courtyards,roads & parking lots.
10 HOUR CHARGE TIME IS BASED ON CLEAR & BRIGHT SUNNY DAY WITH CORRECT PANELORIENTATION TO THE SUN.
Flybrother FAT 101 Fat Tire Electric Bike – 750W, 48V 20Ah Battery, 40 KM/H Max Speed
Conquer every road with confidence on the Flybrother FAT 101 Off-Road Electric Bike. Built tough with fat tires and a lightweight aluminum alloy frame, this e-bike offers stability, power, and versatility for both rugged terrain and city streets.
Powered by a robust 750W motor and a high-capacity 48V 20Ah lithium battery, the FAT 101 delivers impressive range – up to 100 KM on electric mode and 130 KM with pedal assist. Reach speeds of up to 40 KM/H and enjoy smooth control thanks to the SHIMANO 7-speed gear system and front/rear disc brakes.
Whether you're commuting, exploring trails, or hauling gear, this bike is ready for it all – complete with front and rear racks, an easy-to-read LCD display, and a folding frame for compact storage.
Technical Specifications:
Feature
Specification
Model
FAT 101
Brand
Flybrother
Type
Off-Road / Fat Tire Electric Bike
Frame Material
Aluminum Alloy
Speed System
SHIMANO 7-Speed
Brakes
Front & Rear Disc Brakes
Motor
750W
Battery
48V 20Ah Lithium Battery
Charging Time
6–8 Hours
Electric Range
80–100 KM
Assist Range
120–130 KM
Max Speed
40 KM/H
Display
YL-80 C LCD
Bike Size
164 × 58 × 105 CM
Carton Size
159 × 32 × 87 CM
Net Weight
31.8 KG
Gross Weight
38.2 KG
Flybrother MTB 301 Electric Mountain Bike – 250W Motor, 36V 14.5Ah Battery, SHIMANO 21-Speed
Take your ride to the next level with the Flybrother MTB 301 Electric Mountain Bike – the perfect combination of power, performance, and precision.
Designed for adventurous terrain and smooth road cycling, this e-bike features a durable aluminum alloy frame, reliable SHIMANO 21-speed gear system, and a high-capacity 36V 14.5Ah lithium battery.
Enjoy up to 55 KM on electric mode and 110–120 KM with pedal assist, making it ideal for commuting, trail riding, or weekend adventures.
With its responsive disc brakes, LCD display, and a powerful 250W motor, the Flybrother MTB 301 delivers control, comfort, and confidence on every ride.
Technical Specifications:
Feature
Specification
Model
MTB 301
Brand
Flybrother
Frame Material
Aluminum Alloy
Speed System
SHIMANO 21-Speed
Brakes
Front & Rear Disc Brakes
Motor
250W
Battery
36V 14.5Ah Lithium Battery
Charging Time
6–8 Hours
Electric Range
Up to 55 KM
Assist Range
110–120 KM
Max Speed
25 KM/H
Display
YL-80 C LCD
Bike Size
175 × 70 × 110 CM
Carton Size
159 × 32 × 87 CM
Net Weight
21.7 KG
Gross Weight
26.7 KG
The Freedom Won eTower is an economical and modular Life PO4 Solution for residential and light commercial applications
5kWh battery with a 90% DoD
Stackable up to 4 Units (20kWh Total)
Wide range Inverter compatibility
10-Year Limited warranty
Module interface pedestal included (no cabinet required)
5U module design
4000 charge and discharge cycles
Stacked horizontally onto each other to form a tower with pedestals included, (one per module) or 19 inch rack mounted with brackets (cabinet excluded).
Vertical mounting on floor or wall (shelf/bracket) with terminals facing upwards
Comes complete with One e5000 plastic pedestal for tower stacking (cleats for 19” rack not included but available from Freedom Won if required).
All Acccessories Included:
1 x 1.8m red 35mm battery cable with m6 lug
1 x 1.8m black 35mm battery cable with m6 lug
2 x busbar connectors (x1 heatshrink in black and x1 heatshrink in red)
1 x inter modular comms cable
1 x 1.8m long comms cable for Victron Inverters
1 x 1.8m long comms cable for Type 1 inverters
1 x 1.8m long RS485 comms cable this is for Voltronic inverters (Kodak) communication
The converter is not required for the eTower
Handle electricity spikes with a 1.5C
DOD 90%
1.5C Discharge
10-year warrantywarranty
Compatible with most major brands
Product Description
One of the only 1.5C Discharge batteries available, a good sized battery that packs a big punch.
Why would you want a 1.5C discharge battery?
One of the problems with batteries that don't have much discharge capacity is when under high temporary load the whole system trips.
If you are using your battery power during the evening or during load shedding you often want to use a kettle, microwave or turn on a pump. With a 1.5C discharge battery it will handle that spike in power.
This product has a decent size that can be paralleled to make a serious battery bank with high performance, great for commercial purposes as well as residential.
Additional information
Weight
50.88 kg
Dimensions
222.6 × 442 × 512 mm
Brand
Greenrich
Storage Size
5kWh
Storage Type
Lithium-ion
Ah
96.6Ah
DoD
90%
Volt Size
51.2V
Cycles
6000
Parallel
Yes
BMS System
Yes
Warranty
10 Years
Product type
Battery
Handle electricity spikes with a 1.5C
DOD 90%
1.5C Discharge
10-year warrantywarranty
Compatible with most major brands
Product Description
One of the only 1.5C Discharge batteries available, a good sized battery that packs a big punch.
Why would you want a 1.5C discharge battery?
One of the problems with batteries that don't have much discharge capacity is when under high temporary load the whole system trips.
If you are using your battery power during the evening or during load shedding you often want to use a kettle, microwave or turn on a pump. With a 1.5C discharge battery it will handle that spike in power.
This product has a decent size that can be paralleled to make a serious battery bank with high performance, great for commercial purposes as well as residential.
Additional information
Weight
50.88 kg
Dimensions
222.6 × 442 × 512 mm
Brand
Greenrich
Storage Size
5kWh
Storage Type
Lithium-ion
Ah
96.6Ah
DoD
90%
Volt Size
51.2V
Cycles
6000
Parallel
Yes
BMS System
Yes
Warranty
10 Years
Product type
Battery
